| specification | Working temperature | Packaging | Working voltage | The output current | Function description | Available |
|---|---|---|---|---|---|---|
| HEX-302C | -40~125°C | DIP-4 | 55mV<VH<75mV | 10mA | Linear hall sensor | 10000 |
| HEX-302B | -40~110°C | 4-SIP | 122mV~204mV | 10mA | Linear hall sensor | |
| HEX137AO | -40~85°C | TO-92 | 4.5-24V | 3-5mA | Bipolar hall switch | 10000 |
| HEX-1789 | -30~85°C | SON | 1.6V-5.5V | 0.5mA | A high sensitive all hall switch | 10000 |
| HEX-454 | -40~85°C | SOT-23 | 1.65-6V | 1.4mA-3mA | Single polarity low-power hall switch | 10000 |
| HEX-9145 | -40~85°C | SOT-23 | 2V-6V | -1mA-4.5mA | Nonpolar Holzer switch | 10000 |
| HEX-456-S | -40~150°C | SOT-23 | 3.0V-30V | 1.2mA-2.0mA | High pressure all hall | 10000 |
| HEX-1779 | -40~85°C | DFN1216-4L | 2.4V-5.5V | 3-6mA | The whole hall switch polarity | 10000 |
| HEX-1776 | -40~85°C | 6-6L-EDFN1216-4 | 1.65-3.6V | The whole hall switch polarity | ||
| HEX-9245 | -40~85°C | SOT-23-3L | 1.65V-6.0V | -1mA-4.5mA | The infinite hall | 10000 |
| HEX-9632 | -40~125°C | TO-92 | 1.8-6V | 10mA | Magnetic resistance all hall | 10000 |
| HEX181 | -40~150°C | TO-92S | 4.5-24V | 25mA | Unipolar hall switch | 10000 |
| HEX6325 | -40~150°C | SOT-23/SOT-553 | 1.8-5.5V | 10mA | All very low power switch magnetic resistance hall | 10000 |
| HEX454ESQ | -40~85°C | QFN2020-3 | 1.65-6V | 1.4-3mA | Single polarity low-power hall switch | 10000 |
| HEX1201 | -40~125°C | TO-92 | 1.8-6V | 10uA | low-power hall | 10000 |
